Vibration Test Capabilities

THP Systems have a custom built vibration test cell unit ready for a range of vibration test capabilities. Get in touch today to see what we have available, capabilities not listed may be able to be accounted for at our test lab. Alongside vibration testing, we can offer expert training programmes on vibration testing, to help your internal engineers get to grips with testing vibration.

Vib1 - 40kN with Horizontal Slip Table

  • Sine Force: 40000N
  • Random Force: 40000N
  • Shock Force: 80,000N
  • Armature Size: 400mm
  • Frequency Range: DC-2,000Hz
  • Displacement: 75.0mm Peak to Peak (3”)
  • Velocity: 2.0m/s
  • Max Acceleration – Sine: 100g pk (1000m/s²)
  • Max Acceleration – Random: 87.5grms (875m/s²)
  • Max Payload: 5000kg

Horizontal Axis Slip Table

  • Dimension: 700 x 700 mm
  • Frequency Range: Up to 2000Hz
40knshaker

Vib3 – 16kN - i230 ECO System

  • Sine Force: 16000N
  • Random Force: 16000N
  • Shock Force: 32000N
  • Armature Size: 200mm
  • Frequency Range: DC-3,000Hz
  • Displacement: 64mm Peak to Peak
  • Velocity: 2.2m/s
  • Max Acceleration – Sine: 127.5g pk (1250m/s²)
  • Max Acceleration – Random: 89grms (875m/s²)
  • Max Payload: 300kg
IMVI230

Vib4 – 6.6kN / 600mm Sliptable

  • Sine Force: 6,583N
  • Random Force: 6,050N
  • Shock Force: 13,166N
  • Armature Size: 185mm
  • Frequency Range: DC-4,000Hz
  • Displacement: 25.4mm Peak to Peak (1”)
  • Velocity: 1.78m/s (70.07in/s)
  • Max Acceleration – Sine: 93.7g pk (918.8m/s²)
  • Max Acceleration – Random: 50grms (490.3m/s²)
  • Max Payload: 227kg

Vib5 – 0.67kN

  • Sine Force: 667N
  • Random Force: 556N
  • Armature Size: 110mm
  • Frequency Range: DC-6,300Hz
  • Displacement: 25.4mm Peak to Peak (1”)
  • Velocity: 1.06m/s (42in/s)
  • Max Acceleration – Sine: 68.5g pk (672m/s²)
  • Max Acceleration – Random: 57.3grms (562m/s²)
  • Max Payload: 25kg

HV-36

  • 2,404kgs (5300 lbs) Force Actuator
  • 102mm (4 inch) stroke (peak-to-peak)
  • 2,722kgs (6000 lbs) Reaction Mass
  • 915 x 915mm (36” x 36”) Table Size
  • 20HP Hydraulic Power Supply
  • Digital Vibration Controller with Sine, Random and Road Load Data (RLD)
  • Perform – ISTA, ASTM and Amazon 6



Hv36x36 302x400
